Laboratory Spiral Test Rig
Standard sump/pump rig consists of:
- 400 liter sump ( Tank)
- 1 each: 12-way slurry distributor, Y-Splitter and 1� x 1 slurry pump.
- Miscellaneous Plumbing
- A product sampling device to manually sample multiple products from one spiral simultaneously
- Safety ladders and hand rails
- Structural spiral support frame.
- Support frame can be disassembled for easy shipping
- Spirals sold separately
Power requirement: 3 HP, 4 pole, 1415 rpm, 3 phase. 415V.
Capacity:
Model |
Uite |
STS-600 |
STS-400 |
Screw diameter |
mm |
600 |
400 |
Spiral size |
mm |
360 |
240 |
Spiral in the first few |
|
2 |
2 |
Each of the first few |
Film |
5 |
5 |
Feed |
mm |
0.3 |
0.3 |
Feed density |
% |
20-40 |
20-40 |
Caparating Size |
t/h |
0.8-1.2 |
0.1-0.2 |
Overall dimensions |
mm |
700/700/2730 |
460/460/1500 |
Weight |
kg |
90 |
60 |
